In a customer test in the igus Customer Testing Area (CTA), a gluing process was simulated using a Dobot CRA5 robot. Instead of using a syringe and adhesive, the test involved tracing the contour only. This simulation demonstrates the precise motion control and repeatability of the Dobot CRA5. The robot follows the specified contour exactly, showcasing its potential use in real gluing applications to achieve consistent and accurate results. This type of simulation is particularly useful for testing and optimizing the robot’s capabilities before applying actual adhesive in practical scenarios.
